    Chuck Type Reagent Tube Liquid Filling Capping Labeling Machine with 800 KG Capacity

    Ask Lasest Price
    Brand Name : GH
    Supply Ability : 20 Set/Sets per Month
    Price : $50,000.00/sets >=1 sets
    • Product Details
    • Company Profile

    Chuck Type Reagent Tube Liquid Filling Capping Labeling Machine with 800 KG Capacity

    Recommend Products
    Product Overview
    Chuck Type Reagent Tube Liquid Filling Capping Labeling Machine with 800 KG Capacity
    Chuck Type Reagent Tube Liquid Filling Capping Labeling Machine with 800 KG Capacity
    Chuck Type Reagent Tube Liquid Filling Capping Labeling Machine with 800 KG Capacity
    Product Paramenters

    Chuck type filling, capping and labeling all in one machine


    Technical parameters:

    1, Suitable bottle type: according to customer sample (1 bottle)
    2, Bottle feeding form: vibration bottle sorter automatic bottle feeding
    3, Number of filling: 3
    4, Filling form: peristaltic pump + clamp flowmeter filling (quantitative flow meter)
    5, Filling capacity: about 1.6ml
    6, Filling accuracy: ±5%
    7, Cap sorting form: vibration cap sorter
    8, Cap feeding: automatic buckle cap and put cap
    9, The number of caps: 3
    10, Screw cap form: servo screw cap
    11, Cap height detection: electric eye detection (automatic elimination)
    12, Production speed: about 3000 bottles/hour
    13, Material: The frame adopts 304# stainless steel
    14, Filling nozzle and material tank contact liquid parts material: 304# stainless steel, silicone tube, teflon tube
    15, The whole machine power: about 5KW
    16, Program control: PLC+ touch screen
    17, Air pressure: 0.6-0.8mpa
    18, Power supply: AC220V/380V, 50/60Hz.

    NO.
    item
    value
    1
    Suitable bottle type
    according to customer sample (1 bottle)
    2
    Bottle feeding method
    vibration bottle sorter automatic bottle feeding
    3
    Number of filling heads
    3
    4
    Filling form
    peristaltic pump + clamp flowmeter filling (quantitative flow meter)
    5
    Filling capacity
    about 1.6ml
    6
    Cap feeding
    automatic buckle cap and put cap
    7
    Filling accuracy
    ±5%
    8
    Cap sorting form
    vibration cap sorter
    9
    The number of caps
    3
    10
    Screw cap form
    servo screw cap
    11
    Cap height detection
    electric eye detection (automatic elimination)
    12
    Production speed
    about 3000 bottles/hour
    13
    Material
    The frame adopts 304# stainless steel
    14
    Filling nozzle and material tank contact liquid parts material
    304# stainless steel, silicone tube, Teflon tube
    15
    The whole machine power
    about 5KW
    16
    Power supply
    AC220V/380V, 50/60Hz.
    17
    Program control
    PLC+ touch screen
    18
    Air pressure
    0.6-0.8mpa
